Product Description
Prepainted Galvalume Steel Coils produced by Rogosteel use galvanized steel coils as the substrate. After surface pretreatment, including cleaning to remove impurities and oil, and composite oxidation and passivation treatment, the surface is coated with PE, SMP, and PVDF paint. The coating is then baked and solidified, making these coils particularly suitable for applications in corrosive and coastal areas.
| Specifications | Details |
| Product Name | Prepainted Galvalume Steel Coil |
| Material Standards | EN 10346, DX51D+AZ, S220GD+AZ, S250GD+AZ, S280GD+AZ, S320GD+AZ, S350GD+AZ, S550GD+AZ |
| Thickness Range | 0.13mm - 0.8mm |
| Width Range | 600mm - 1250mm |
| Paint Thickness | Primer:PU or Epoxy 5µmTopcoat:15~30µmBack Primer:PU or Epoxy 2µmBack Coat:PE or Epoxy 5~20µm |
| Types of Paint Available | PE, SMP, HDP, PVDF |
| Coil ID | 508mm / 610mm |
| Coil Weight | 3-8 tons |
| Protective Film Thickness | 30-80 microns |
| Coating Structure | 2/2 or 2/1 coating structures |
| Warranty | 40 years in North America |
| Galvalume Coating Weight | 150g (AZ150) |
| Suitable Environments | Corrosive and coastal areas |
| Production Process | Uncoiling, sewing, degreasing, chemical pretreatment, coating, baking, cooling, inspection, splitting, coiling |
| Applications | Roofing, guttering, sandwich panels, facades, cold storage panels, rolling doors |
